Chaoqiang,s strictly controls the accessories to ensure the quality of each machine, reliable and stable performance, low mechanical failure rate, and high-speed packaging of products. Our bearings and end seals are reinforced to reduce wear on the machine and reduce downtime.
1.Main performance and Specification
· Three servo motors, converter and PLC controller, flexible bag length setting and cutting, saving time and film.
· human-machine interface, convenient and quick parameter settings, when the product is sensed by the sensor, then it will be packing automatically, otherwise, it will be stopped.
· Self-diagnosis failure function, failure displayed clearly.
· High sensitive optical electric color mark tracking system and digital input cut position, which makes the sealing and cutting more accurate.
· Separated PID control system for temperature, suitable for various packing materials.
· Stopping the machine in a selected position, no sticking on the knife and no waste of the film.
· Simple driving system, reliable working, convenient maintenance. All controlled by a program, convenient for function adjusting and
Model | CQ-350SF |
Film width | Max.340mm |
Film roll diameter | Max. 320mm |
Bag length | Any long size controlled by sensor |
Bag width | 50-160mm |
Product Height | Max. 60mm |
Weight | about 500kg |
Packing Speed | 25 meters / minute (equivalent to 80 bags / minute) |
Power Specicions | 220V,50/60HZ 2.4KW |
Machine size( L*W*H) | 3525*765*1375mm |
