Scope of application:
Metal foreign matter detection in various textiles, plastic products, toys, aquatic products, food (food additives, condiments), pharmaceuticals, health products, cosmetics, etc., such as iron, copper, aluminum, stainless steel and other metal particles, can be tested in bulk , bagged, bottled, boxed.
| Power supply: | |
|---|---|
| Dimension: | |
| Power: | |
| Machinery Test Report: | |
| Quantity: | |
CQ-818
CHAOQIANG
Product Details:
1.Wide range of applications
2.High-precision measurement
3.304 stainless steel is durable
4.Food grade belt safety.
5.Imported chip digital technology and high technology
6.Stable performance and anti-interference
7.Product effect automatic learning function Anti-check function
8.100 kinds of product parameter memory storage
9.Secret function security and privacy
10.Obtained a patent for beautiful appearance
11.Complete certificates, including inspection certificate, instruction manual, factory video, etc.
Sensitivity Chart
Model Type. | CQ-818 | |||||||
4010 | 4012 | 4015 | 4020 | 4025 | 4030 | 4035 | ||
Detection channel width (mm) | 400 | |||||||
Detection channel height (mm) | Conventional machine | Non-standard custom inspection window height | ||||||
100 | 120 | 150 | 200 | 250 | 300 | 350 | ||
Sensitivity | Fe ( ≥ ømm) | 0.7 | 0.8 | 1.0 | 1.5 | 2.0 | 2.5 | 2.8 |
Cu/Al ( ≥ ømm) | 1.3 | 1.5 | 1.8 | 2.0 | 2.5 | 2.8 | 3.7 | |
stainless steel ( ≥ ømm) | 1.5 | 2.0 | 2.0 | 2.5 | 3.0 | 3.3 | 4.3 | |
The machine material | The whole machine is made by 304 stainless steel cold drawing process | |||||||
Type of alarm | Automatically shut down and alarm when metal foreign body is detected, optional customized rejection device: flap, lever, push rod, air jet, etc. | |||||||
Machine size | 1400x820x900 (LxWxH) Customized | |||||||
Machine weight | about 200Kg | |||||||
Power | 220V 50-60Hz 120w | |||||||
Loading capacity | ≤15Kg speed:30m/min | |||||||
Working desk | height 700mm /Customized | |||||||
1.Conventional machines are available from stock, and the sensitivity parameter is the all-round test value of the empty machine. 3.The actual value is related to the test height of the machine and the product itself. | ||||||||
1. Standard wooden case.
2. Completely machine contain:Machine and product Manual
3. Machine come into use, customer only need prepare power for the machine.
4. It has been debugged and attached the test card before shipment, and the test video will be provide.
6.Q: How about your product warranty?
A: The one-year warranty. We will provide you with lifetime technical support.
