| Quantity: | |
|---|---|
CQ-806
chaoqiang
model | CQ-810 | |||||||
detection channel width(mm) | 4010 | 4012 | 4015 | 4020 | 4025 | 4030 | 4035 | |
400(Customizable wdth200~2000) | ||||||||
detection channel heiht(≧Φmm) | conventional mahine detection window height | non-standard custommized detection window width | ||||||
100 | 120 | 150 | 200 | 250 | 300 | 350 | ||
Sensitve (≥Φmm) | lron ball Fe diameter | 0.7 | 0.8 | 1.0 | 1.5 | 2.0 | 2.5 | 2.8 |
Non-ferrous metals such as copper and aluminum | 1.3 | 1.5 | 1.8 | 2.0 | 2.5 | 2.8 | 3.7 | |
stainless steel diameter | 1.5 | 2.0 | 2.0 | 2.5 | 3.0 | 3.3 | 4.3 | |
Body material | The whole machine is made by 304 stainless steel cold drawing process | |||||||
Alarm method | Automatic detection of foreign objects stops,and output 12V buzzer alarm sound（A variety of rejection devices can be customized: flip, pull rod, push rod, air jet, etc.） | |||||||
Machine size | ≈L:1400×W:820×H:900,the size of the costormized product is based on the actual product | |||||||
Machine weight | ≈200kg | |||||||
Power supply | 220V 50Hz 120W | |||||||
weighing capacity | ≤20 Speed:25~30m/min(not adjustable) | |||||||
Working desk | 700mm(can be customized) | |||||||
1、Strong versatility: the machine standardized structure and standardized man-machine interface can complete the weighing of various materials.
2、Simple operation: Using Weilun color human-machine interface, fully intelligent, humanized design; Conveyor belt is easy to disassemble, easy to install and maintain, easy to clean.
3、Speed adjustable: frequency conversion control motor, speed can be adjusted according to needs.
4、High speed, high precision: high precision digital sensor, fast sampling speed, high precision.
5、Zero tracking: manual or automatic zero clearing, and dynamic zero tracking.
6、Report function: built-in report statistics, report can be generated in EXCEL format, can automatically generate a variety of real-time data reports, U disk can store more than 1 year of statistical data, support the production status at any time; Provide factory parameter setting recovery function, and can store a variety of formula, convenient replacement of product specifications.
7、Interface function: reserved standard interface, convenient data management, communication and connection with PC and other intelligent devices.
8、Self-learning: it is not necessary to set parameters after creating product formula information. The self-learning function is used to automatically set suitable parameters for the device and save them for convenient call when switching products next time.
9、Solid SUS304 stainless steel structure enable for good performance.
Model | CQ-XP1010 | CQ-XP210 | CQ-XP300 | CQ-XP400 | CQ-XP500 | CQ-XP600 |
Weighing range | 200g | 1000g | 3000g | 15kg | 40kg | 50kg |
Weighing accuracy | ±0.05g-±0.1g | ±0.3g-±0.5g | ±0.5g-±2g | ±2g-±10g | ±5g-±15g | ±8g-±20g |
Minimum scale | 0.01g | 0.1g | 0.1g | 1g | 1g | 5g |
Conveyor speed | 20-60m/min | 30-100m/min | 30-90m/min | 30-70m/min | 20-35m/min | 15-25m/min |
Sorting speed | 180pcs/min | 160pcs/min | 80pcs/min | 70pcs/min | 30pcs/min | 30pcs/min |
Belt height | 700mm±30mm | 700mm±30mm | 700mm±30mm | 700mm±30mm | 700mm±30mm | 700mm±30mm |
Weighing part | 250(L)*120(W)mm | 400(L)*210(W)mm | 450(L)*300(W)mm | 620(L)*400(W)mm | 900(L)*500(W)mm | 1200(L)*600(W)mm |
Rejection part | 400(L)*120(W)mm | 700(L)*210(W)mm | 900(L)*300(W)mm | 900(L)*400(W)mm | 900(L)*500(W)mm | 935(L)*600(W)mm |
