CQ-918
chaoqiang
Digital intelligent Metal detector for bottle
Application:
The metal detector is widely used in Aquatic products,meat and poultry products,
preserved food,flour products,dried fruit,vegetables ,chemical materials and so
on to ensure contaminated product is detected.
Characteristics:
1 Adopt phase discriminating technology that can effectively refrain product effect;
2 Adopt advanced DSP technology and leading intelligent algorithm which can improve
detection sensitivity and promote stability of the machine;
3 Be able to detect various metals like iron, stainless teel,copper and aluminum, etc;
4 LCD display, Chinese & English operating menu;
5 Self-learning function contributes to automaticallychoose suitable working parameters
according to different products;
6 Memory function for registering various products
7 Simple conveyor structure makes it convenient to disassembleand assemble;
8 Special design of conveyor belt to avoid deviation;
9 Made of stainless steel, fairly good waterproof ability;
10Excellent quality with attractive price.
Our company provides different specification and style metal detector for different products.
Technical Parameter
Model | IMD-I | IMD-II | |||
Specifications | 4008, 4012 4015, 4018 | 5020,5025 | 4008, 4012 4015, 4018 | 5020,5025 | |
Detection Width | 400mm | 500mm | 400mm | 500mm | |
Detection Height | 80mm,120mm 150mm,180mm | 200mm 250mm | 80mm,120mm 150mm,180mm | 200mm 250mm | |
Sensitivity | Fe | Φ0.5mm,Φ0.6mm Φ0.7mm,Φ0.8mm | Φ1.0mm Φ1.2mm | Φ0.5mm,Φ0.6mm Φ0.7mm,Φ0.8mm | Φ1.0mm Φ1.2mm |
SUS304 | Φ1.0mmΦ1.2mm Φ1.5mmΦ2.0mm | Φ2.0mm Φ2.5mm | Φ0.8mm,Φ1.0mm Φ1.2mm,Φ1.5mm | Φ1.5mm Φ2.0mm | |
Belt Width | 360mm | 460mm | 360mm | 460mm | |
Loading Capacity | 5kg~10kg | 20kg~100kg | 5kg~10kg | 20kg~100kg | |
Display Mode | LCD Liquid Crystal (FDM touch screen is optional) | ||||
Operation Mode | Button Input (Touch input is optional) | ||||
Product Storage Quantity | 52 kinds | ||||
Packing Form | Standard plastic or cardboard, metal film (aluminum) and bulk | ||||
Conveyor Belt | Food Grade PVC (PU and Chain Conveyor are optional) | ||||
Belt Speed | Fixed 25m/min (Variable speed is optional) | ||||
Alarm | Alarm and belt stops (Alarm lamp and rejecter are optional) | ||||
Power Supply | AC220V (Optional) | ||||
Levels of Protection | IP30/IP66 | ||||
Main Material | SUS304 | ||||
Main Advantages |
| ||||
