portable magnetic toy Needle Detector

Features:

1. Check the window height specifications, available to customers arbitrarily selected according to need;
2, eco-friendly, machine ten minutes without an object by itself off.
3, with automatic detection of the defective function backwards.
4, high sensitivity, high anti-jamming metal alloy shell paint, more durable,
5, from data acquisition to all motor control using digital signal processing (DSP), highly intelligent;
6, with manual and automatic control of two feature selection, using the operation more convenient and flexible.
7, can accurately count the total number of qualified defective
8, super load-bearing, 50KG cargo run smoothly
9, super anti-jamming performance, highly balanced detection zone without blind spots, can eliminate the interference of iron oxide

Technical parameters:

Model: CQ-800A High probe bearing type conveyor type needle machine
Detection method: magnetic induction, digital circuit processing.
Detection sensitivity: Φ0.8mm-2.5mm (height higher detection probe corresponding reduced sensitivity)
Sensor adjustment: 1-100 adjustable
Detection width: 600mm non-standard size (custom)
Detection height: 10-20cm non-standard size (custom)
Alarm: sound and light alarm and shutdown
Power source: Ac100-240V 50-60Hz
Power: 90W
Dimensions: length of approximately 2000 × 1150 × 950 Width Height (mm)
Net weight: about 250KG
