Features:
1.The core part adopts the advanced digital technology the original imported chip to be carefully developed.and the detection coil is internally filled. It has the characteristics of high detection accuracy,stable performance and strong anti-interference ability.
2.It can be made according to the characteristics of the product,and it has the of detecting and storing the product.About 100 kinds of product applicable scope is wide.
3.Intelligent identification technology, with self-learning and functions,can automatically recognize and remember product features. Effectively eliminate interference caused by various by various “product effects”
4.Simple and friendly operation interface,using a dialogue type LCD screen,quick with simple keying interface .Conveniently setting parameter; detect a variety of products with different signal (characteristics) and set them time .Can guarantee extremely high detection accuracy, to readjust, setup program.
5.Modular component replacement,easy maintenance and quick maintenance.
6.Comply with the requirements of HACCP,GMP and FDA.
7.Shockproof waterproof design,dust proof and water proof function conforms IP-66/IP65 international certification,anti-vibration noise,able to adapt to harsh working conditions.
Technical parameters
Pipeline calibre(mm): 50~150mm
Fe(mm)Test precision: ≥Φ 0.5mm
SUS(mm)Test precision SUS(mm): ≥Φ1.0mm
(t/h) Detection capability(t/h): 3~10t/h
Alarm method: Automatic stop or valve removal optional
Wipe-out mode: Pneumatic ruled out
Air Requirements: ≥0.5Mpa
Power supply: AC220V±10% 50-60HZ(customizableAC110V or 380V.
Remark:
1. the above technical indicators are metal detector,and the actual sensitivity is related to the factory environment and product effect.
2. The amount of metal detected per hour is related to the specific gravity and flow rate of the product.
3. Special specification metal detector can be customized according to customer is requirement.
